PicoBNC+ 10:1 Pico Attenuator (pt-TA506)

AES#:
pt-TA506

$76.00
Qty:

California Residents: Proposition 65 Warning

Eligible for FREE Ground Shipping(Eligible for FREE Ground Shipping)

The compact design of the TA506 contains the entire attenuator circuit of a traditional oscilloscope probe, but within a 4 mm connector body. With a fixed x10 attenuation it is intended for high-speed signals like CAN, FlexRay and also for higher voltage signals such as primary ignition.

The TA506 is automatically recognised by PicoScope software when connected to the scope.

This accessory is only available for PicoBNC+ and will not work with older PicoScope models.

Specifications

Attenuation ratio 10:1
Bandwidth 20 MHz
Rise time (calculated) 17.5 ns
Input resistance 10 MΩ ±2%
Input capacitance 33 pF ±1 pF
Max. working voltage 400 V pk
Total length 2.85 m nominal
Weight 100 g
