The Upgraded TC004 is a professional thermal inspection tool built for fast, everyday jobsite use. Its 3.5-inch display and TISR-supported imaging deliver clear thermal visuals, while built-in WiFi enables a streamlined workflow for electrical, building, and mechanical inspections.
Larger Display. Clearer Decisions.
The TC004 features a 3.5-inch display that provides a wider and more comfortable viewing experience, making it easier to identify hotspots and temperature differences during daily inspections.
Sharp, Clear Thermal Images
With a 256×192 infrared resolution (TISR-enhanced up to 512×384), the TC004 captures detailed thermal images that help you detect temperature variations and make confident decisions on the first pass.
Laser Pinpointed Inspection Accuracy
A built-in red laser pointer marks the measurement area, making it easier to align thermal images with the actual target and locate anomalies during inspections.
Expanded Storage for Thorough Documentation
Equipped with 64GB of built-in storage, the TC004 allows you to store thousands of images and videos, supporting thorough documentation throughout the workday without interruptions.
Flexible Connectivity for Fast Reporting
Integrated Wi-Fi connects to the TopInfrared mobile app, while a USB connection supports file transfer and analysis through TopView PC software. Sync files quickly, perform thermal analysis, and generate professional inspection reports more efficiently.
Long Runtime for Extended Inspections
Powered by a 5,000 mAh battery, the TC004 delivers up to 8.5 hours of continuous operation and fully recharges in just 2 hours, supporting extended inspections with minimal downtime.
Built for Demanding Inspection Environments
Built for real-world environments, the TC004 features IP54-rated protection against dust and splashes, 2-meter drop resistance, and an integrated LED light to improve visibility in dark or confined inspection areas.
Specifications
- Display: 3.5-inch, 640x480 resolution
- Thermal Camera: 256x192 (512x384 TISR)
- Temperature Range: -20 to 550℃ (-4 to 1022℉)
- Battery Life: 8.5 hours
- Heat Sensitivity: 40mK
- Field of View: 56°X42°
- Frame Rate: 25Hz
- PC-Based Analysis Software support
- Storage: 64GB eMMC
In the Box
- TC004 Thermal Camera
- Universal Travel Adapter
- USB Cable (USB-A to USB-C)
- Storage Bag
- User Manual
- 1yr warranty
