PicoScope 4823 8-Channel Professional Diagnostic Kit

AES#:
pt-PQ184
UPC:
2019.07.01

$4,999.00
Qty:

California Residents: Proposition 65 Warning

Eligible for FREE Ground Shipping(Eligible for FREE Ground Shipping)
Description
More Info
Specifications

The PQ184 8-Channel Professional Diagnostic Kit includes the PicoScope 4823, a high-resolution, 8-channel automotive oscilloscope that features a common-ground configuration, a maximum input range of 50V (protected to 100V), and a maximum sample rate of 80MS/s (10MS/s if using all 8 channels).

The PicoScope 4823 is a low-cost, portable solution for multi-input applications. With 8 high-resolution, high-speed analog channels you have a perfect solution for a range of diagnostic needs such as:

  • V6/V8 Cam timing (4/6 cams plus crank, and sometimes a WPS), and VVT timing systems.
  • Trucks, construction and agriculture equipment that typically requires a mix of electrical and hydraulic measurements on multiple valves simultaneously to diagnose problems with system interaction.
  • Full system diagnosis on components (including power, ground, signals, current)
  • Diagnosing faults on multiple serial busses (CAN, CAN FD, LIN, FlexRay)

The 256 MS deep memory allows several seconds of capture at the full sampling rate (ideal for long captures of serial data or looking for glitches). Managing all this data calls for some powerful tools which are built into PicoScope software: zoom factors of several million are possible, waveform buffer, mask limit test, serial decode, hardware acceleration, deep memory making the PicoScope 4823 one of the most powerful diagnostic oscilloscopes on the market.



PQ184 PicoScope 4823 8-Channel Professional Diagnostic Kit contents

Item Qty   Description
PA186 1   Carry Case: Heavy Duty PS4823
PR361 1   PS4823 8 channel 20MHz 80MS/s USB3.0 automotive scope
MI121 1   Cable: USB2 4.5m
TA155 1   Cable: USB 3.0 blue 1.8m
MI168 2   "S" Hook
TA125 1   Premium Test Lead: 3M BNC to 4mm blue permanent ground
TA126 1   Premium Test Lead: 3M BNC to 4mm red permanent ground
TA127 1   Premium Test Lead: 3M BNC to 4mm green permanent ground
TA128 1   Premium Test Lead: 3M BNC to 4mm yellow permanent ground
TA472 4   Premium Test Lead: 3M BNC to 4mm black permanent ground
LA732 1   Label: Destiny 8 channel scope sheet of coloured labels
TA197 4   Divide by 10 attenuator
TA375 2   Oscilloscope probe: 1:1/10:1 switchable 100 MHz, BNC
MI074 8   Secondary Ignition Pickup (automotive test lead)
TA037 4   HT extension test lead
TA204 1   Insulated COP and signal probe
TA033 1   Lead: BNC to BNC with earth clamp
TA106 1   Earth wire for coil pack 45cm long
TA018 1   60A DC current clamp with BNC connector
TA167 1   Precision 2000A/200A current clamp BNC
TA234 1   Current Clamp: 30A
TA329 1   Ultrasonic Parking Sensor Detector
TA330 1   Keyless Entry Detector
TA034 1   Breakout lead for ATC style fuses
TA035 1   Extension  lead for mini style fuses
TA168 1   Extension lead for JCASE fuse
TA206 1   Extension lead for maxi style fuses
TA324 1   Premium 6-way breakout lead set
PA147 1   6 pocket roll up pouch in black Pico branded
TA008 1   Electronics Acupuncture Probes
TA001 2   Multimeter style test probe (black)
TA002 2   Multimeter style test probe (red)
TA003 2   Small crocodile clip (black)
TA004 2   Small crocodile clip (red)
TA005 2   Dolphin clip 1000V CATIII (black)
TA006 2   Dolphin clip 1000V CAT III (red)
TA017 8   4mm shrouded to unshrouded adaptor red
TA157 2   Battery clip 4mm socket (red)
TA158 4   Battery clip 4mm socket (black)
TA161 8   Flexible back pinning probe black
TA162 8   Flexible back pinning probe red



Computer Requirements
To ensure that PicoScope operates correctly, you must have a computer with at least the minimum system requirements to run your Windows operating system, which must be one of the versions listed in the following table. The performance of the PicoScope will be better with a more powerful PC, and will benefit from a multi-core processor.

Item Specification
Operating System
32–bit or 64–bit editions of:
- Windows 10
- Windows 8 (not Windows RT)
- Windows 7

Processor

As required by the operating system
Memory

As required by the operating system
Free disk space

As required by the operating system
Ports

USB 3.0 or USB 2.0 ports(s)



























PicoScope is suitable for use with any modern vehicle

The Pico Automotive Diagnostics Kit can be used to measure and test virtually all of the electrical and electronic components and circuits in any modern vehicle including:

- Ignition (primary and secondary)
- Injectors and fuel pumps
- Starter and charging circuits
- Batteries, alternators and starter motors
- Lamda, Airflow, knock and MAP sensors
- Glow plugs / timer relays
- CAN bus, LIN bus and FlexRay



Educators share with the whole class



Educators will also benefit from using the PicoScope because it allows an entire classroom to see live vehicle waveforms when you have your PC hooked to an LCD projector.



Waveform Library

One of our most popular features of the PicoScope is the Waveform Library, you can search a global data base of waveforms uploaded by PicoScope users from around the world.



To access the Waveform Library you must have an automotive scope connected to your PC and have a valid user name and password to the Pico Automotive Forum.


Once logged into the Waveform Library Browser you will find numerous “Search Options” allowing you to locate a relevant waveform for a specific manufacturer or model. You can also search for a waveform using just the engine code, allowing you to locate a waveform that may not have been saved under your search entry, but is applicable to other models or manufacturers using that engine.






The ConnectDetect icons remain on screen briefly once a good connection has been established, and then become transparent to prevent obscuring the waveform under review. Should the connection be lost during a capture, the relevant icons will return in bold to warn of a connection problem.









PicoScope 4823 Specifications

Channels 8
Vertical resolution 12 bits (up to 16 bits in enhanced resolution mode)
DC accuracy ±1% of full scale ±300 μV
Input sensitivity 2 mV/div to 10 V/div (10 vertical divisions)
Input ranges (full scale) ±10 mV to ±50 V in 12 ranges
Input characteristics 1 MΩ in parallel with 19 pF
Input type BNC
Input coupling Software selectable AC/DC
Input overvoltage protection ±100 V (DC + AC peak)
Buffer memory 256 MS shared between active channels
Timebase ranges 20 ns/div to 5000 s/div
Bandwidth (-3 dB) 20 MHz
10 MHz (10 mV and 20 mV ranges)
Maximum sampling rate (real time):
1-4 channels in use
5-8 channels in use

80 MS/s
40 MS/s
Maximum sampling rate
(continuous streaming mode)
20 MS/s using PicoScope 6 software
80 MS/s per channel using supplied API,
160 MS/s total across all channels (PC-dependent)
Analog offset range
(vertical position adjustment)
±250 mV (10 mV to 500 mV ranges)
±2.5 V (1 V to 5 V ranges)
±25 V (10 V to 50 V ranges)
SIGNAL GENERATOR
Standard output signals Sine, square, triangle, DC voltage, ramp, sinc, Gaussian, half-sine, white noise, PRBS
Standard signal frequency DC to 1 MHz
Sweep modes Up, down, dual
Triggering Can trigger a counted number of waveform cycles or sweeps (up to 1 billion)
from the scope trigger or manually from software.
Frequency accuracy ±20 ppm
Frequency resolution < 20 mHz
Voltage range ±2 V
Amplitude and offset adjustment Signal amplitude and offset within ± 2V range.
DC accuracy ±1% of full scale
Output characteristics Rear-panel BNC, 600 Ω output impedance
Overvoltage protection ±10 V
ARBITRARY WAVEFORM GENERATOR
Update rate 80 MS/s
Buffer size 16 kS
Resolution 14 bits
ENVIRONMENTAL
Operating temperature range 0 °C to 45 °C (20 °C to 30 °C for quoted accuracy)
Operating humidity range 5% to 80% RH, non-condensing
Storage temperature range -20 to +60°C
Storage humidity range 5 to 95% RH, non-condensing
PHYSICAL CHARACTERISTICS
Dimensions 190 x 160 x 40 mm (approx 7.5 x 6.3 x 1.6 in)
Weight < 0.55 kg (approx 1.2 lbs)
GENERAL
Additional accessories (supplied) USB cable and Safety Guide
PC interface SuperSpeed USB 3.0 (USB 1.1 and USB 2.0 compatible)
Power requirements Powered from USB
Approvals FCC and CE compliant
Warranty 2 years
